Clarkson-Osborn Metric Hand Tap – M6 x 1.0 Plug Tap, Warwick Series, Model TA35063

Description

ITEM #: TA35063

• Premium HSS Hand Tap
• Ground Thread
• Bright Finish
• Available in Taper (7 – 10 thread chamfer), Plug (3 – 5 thread chamfer), and Bottoming Chamfer (1 – 2 thread chamfer)
• The Set part number includes one each of Taper, Plug and Bottoming chamfers
• Designed for Hand Tapping in wide variety of materials in both through hole and blind hole applications
• Thread Standard: M
• Thread Diameter Size TDZ: 6.0
• Thread Pitch Metric TP: 1.00
• Direction: Right Hand
• Thread: 19.0
• Length: 66.0
• Shank Diameter: 6.3
• Flute Count: 3
