Description
Item #: CT72
*Not all available types/sizes are listed here – please contact us for additional options.
- HSS
- Designed to produce a 2B Class of Fit
- Spiral point forces the chips ahead of the tap – designed for through hole applications
- Suitable for various steels (up to 32Rc) and stainless steel
- Ferrous Oxide surface treatment increases wear resistance, improves chip flow and reduces chip welding
- The Ferrous Oxide surface treatment also enables the tap to absorb the lubricant / cutting fluid
| CODE | SIZE | THREAD | LENGTH | SHK DIA | FLTS |
| CT72006 | 6-32 NC | 11/16 | 2″ | 0.141 | 2 |
| CT72008 | 8-32 NC | 3/4 | 2-1/8 | 0.168 | 2 |
| CT72010 | 10-24 NC | 11/16 | 2-3/8 | 0.194 | 2 |
| CT72104 | 4-48 NF | 5/8 | 1-7/8 | 0.141 | 2 |
| CT72110 | 10-32 NF | 11/16 | 2-3/8 | 0.194 | 2 |
| CT72404 | 1/4-20 NC | 13/16 | 2-1/2 | 0.255 | 2 |
| CT72405 | 5/16-18 NC | 7/8 | 2-23/32 | 0.318 | 3 |
| CT72406 | 3/8-16 NC | 1 | 2-15/16 | 0.381 | 3 |
| CT72407 | 7/16-14 NC | 1-1/16 | 3-5/32 | 0.323 | 3 |
| CT72408 | 1/2-13 NC | 1-3/16 | 3-3/8 | 0.367 | 3 |
| CT72504 | 1/4-28 NF | 13/16 | 2-1/2 | 0.255 | 2 |
| CT72505 | 5/16-24 NF | 7/8 | 2-23/32 | 0.318 | 3 |
| CT72506 | 3/8-24 NF | 1 | 2-15/16 | 0.381 | 3 |
| CT72507 | 7/16-20 NC | 1-1/16 | 3-5/32 | 0.323 | 3 |
